Price from

N/A

Power (hp)

46.94/8500

Max. Torque

45.0N·m/6750 r/min

Curb Weight (kg)

210

Tech Specs

  • Model Name

    Morbidelli T502X

    Model Year

    2025

    Category

    Trail

  • Displacement (c.c)

    486

    Type

    2-cylinder inline / 4-stroke / 8-valve / DOHC

    Bore x Stroke

    68×67

    Power (hp/rpm)

    46.94/8500

    Max Torque

    45.0N·m/6750 r/min

    Compression ratio

    10.7:1

    Fuel system

    EFI, Marelli

    Valve train

    DOHC

    Ignition system

    TCI

    Starter

    Electric

    Lubrication system

    Pressure splash lubrication

    Cooling System

    Liquid-cooled

    CO₂ Emissions (g/km)

    93

    Fuel Consumption (l/100km)

    4.1

  • Gear shifting type

    6-speed

    Transmission type

    Chain

    Clutch type

    Slipper clutch

  • Frame

    Diamond

    Front Wheel

    Spokes Tubeless

    Front Suspension

    43mm upside-down telescopic forks, preload adjustable

    Front Suspension travel (mm)

    180

    Front Tyre

    110/80-19, Pirelli

    Rear Wheel

    Spokes Tubeless

    Rear Suspension

    Multi-link shock-absorber, preload adjustable

    Rear Suspension travel (mm)

    69

    Rear Tyre

    150/70-17, Pirelli

    Front Brake

    Double floating discs, 2-piston caliper, J.Juan

    Front brake diameter (mm)

    300

    Rear Brake

    Disc, 1-piston caliper, J.Juan

    Rear Brakes diameter (mm)

    240

  • Curb Weight (kg）

    210

    Seat height (mm)

    830

    Wheelbase

    1458

    Overall length (mm)

    2190

    Overall width (mm)

    935

    Overall height (mm)

    1435

    Ground clearance (mm)

    210

    Fuel Capacity (L)

    18

    Top speed (km/h)

    160

    Max Loadage (kg)

    160

    Battery

    12V, 8A/h

  • MCU (Moto Connectivity Unit)

    Motwi M-link 4G T-BOX GPS, Global Activation

    App Functions

    Real-Time Location, Mov. Alarms, Trips and statistics, Friends Chat and Others

    Anti-Thief options

    Vibration & Movement Sensors with Remote-Cut

    SOS Panic button

    Included

    App Top Features

    Easily Transfer Ownership and Flexible Connectivity Renewal plans

  • Ride Modes selection

    2-adaptable riding modes for various conditions: Standard and Off-Road

    Throttle configuration

    Dual cable throttle control

  • Dashboard type

    Vertical TFT, Rally Inspired, 7 inch Dash with Day/Night Screen Modes

    Navigation screen mirroring

    Included

    Gear indicator

    Included

    USB charging port

    Included (USB + USB-C)

    Handle switch with illumination

    Included

    T-BOX, IoT Connectivity

    Included

  • Headlight

    LED projector + DLR

    Taillight

    LED

    Turn signal

    LED

    Hazard light

    Included

    Automatic lighting system

    Included

  • ABS system

    Bosch ABS

    ABS off function

    Included, Rear only

    Tire pressure monitoring system (TPMS)

    Included
